The compact oxygen sensor delivering high performance

Paracube Micro

Combining our leading Paramagnetic technology with cutting-edge design and manufacturing techniques, the Paracube Micro delivers world-leading oxygen sensing performance in a compact unit.

With a next-generation design ethos, it is manufactured without the use of lead solders or adhesives, offering a degree of system integration, flexibility, compliance and reliability that’s unrivalled in the OEM oxygen sensor market.

Flexible percent-level O2 sensing with a wide range of benefits

The Paracube Micro’s revolutionary design offers medical and OEM manufacturers the perfect combination of fit, form, and function, delivering extensive performance and cost advantages compared with traditional electrochemical cells.

Ideal for our industrial, medical and specialist OEM customers

The Micro’s non-depleting technology means zero ongoing cost of ownership, while daily calibration is eliminated thanks to excellent measurement stability, making the Micro ideal for a wide range of applications, including industrial processes and life-critical healthcare.

Our team, working in partnership with yours

Hummingbird’s experts have considerable experience in applying our sensors to a range of processes. We’ll help you integrate our products into your device and collaborate every step of the way to ensure you get the performance you expect.

Powering air separation technology

The Micro is used in the onsite gas generator products from PCI, helping to produce oxygen at the point of use.

Features and benefits

The Micro is a high-performance, compact oxygen sensor designed for OEM customers in a range of markets

Accurate and reliable

Our proven Paramagnetic sensing technology delivers excellent linearity and stability, ensuring precision oxygen measurements in the 0-100% range.

Unrivalled integration

Offering analog and digital outputs, the Micro utilizes advanced manufacturing techniques that do not require lead solder or adhesives. Its compact design is supported by bespoke housing options for easy integration into OEM instruments.

Low lifecycle costs

Non-depleting Paramagnetic technology significantly reduces the lifetime cost of ownership, compared to electrochemical cells. Stable sensing means there is also no need for daily calibration.

Typical applications

The Micro is ideal for many industrial and medical applications, particularly ambient area monitoring, pressure swing absorber oxygen concentrators, critical care ventilators, neonatal incubators, O2 blenders, and anesthesia delivery systems.

Measurements, technologies and schematics

Size

Molex KK connector: 33.5mm x 30mm x 46.1mm

Molex low profile connector: 33.5mm x 30mm x 37.6mm

Weight

70g

Measures oxygen

The Micro measures percentage O2 from 0-100%

Uses Paramagnetic sensing

Advanced non-depleting Paramagnetic sensing delivers industry-leading levels of linearity, accuracy and reliability.

Certifications

The Micro complies with RoHS 2 directive 2011/65/EU

Downloads available for this product

3D CAD files available upon request

Paracube Sensors – Calibrating out offsets in the Paracube

Paracube Sensors – Calibrating out offsets in the Paracube

Paracube Sensors – Calibrating out offsets in the Paracube

Paracube Micro – 01117 and 01121 Reliability Calculations.

Paracube Micro – 01117 and 01121 Reliability Calculations.

Paracube Micro – 01117 and 01121 Reliability Calculations.

Paracube® Zero Offset Correction and Pressure Compensation

Paracube® Zero Offset Correction and Pressure Compensation

Paracube® Zero Offset Correction and Pressure Compensation

Paracube Micro- Magneto Dynamic Paramagnetic Measurements, The Classic Torque Balance Sensor, Application Note

Paracube Micro- Magneto Dynamic Paramagnetic Measurements, The Classic Torque Balance Sensor, Application Note

Paracube Micro- Magneto Dynamic Paramagnetic Measurements, The Classic Torque Balance Sensor, Application Note
